ACCURL® EURO-PRO Series press brake features an CNC crowning system for improved quality, a servo driven back gauge system for increased speeds, /and 3D capable graphical control unit to simulate bending sequences and collision points.Also has increased working speeds, stroke, daylight, and pressing capacities of GENIUS Series machines. The future - as a result of rising energy costs and increasingly cost efficient speed-controlled drives offered on the market, variable-speed solutions are on the advance.
Item No :
Pro B20400Product Origin :
ChinaColor :
Customer ChooseWeight :
12000ACCURL CNC Press Brake Machine
CNC BACKGAUGE
ACCURL press brake are provided are equipped with a backgauge constituted by a solid structure in order to assure the best repetitiveness and high precision in axes positioning.
| BGA | X | R | Z1 | Z2 | X2 |
| Stroke(mm) | 750 | 150 | UNDER REQUEST | UNDER REQUEST | 190 |
| Speed(mm/s) | 500 | 170 | 2000 | 2000 | 200 |
| Precision(mm) | +0,02 | +0,05 | +0,05 | +0,05 | +0,02 |
| Type of motor | BRUS HLESS | BRUS HLESS | BRUS HLESS | BRUS HLESS | BRUS HLESS |
| Mechanical system | SCREW | SCREW | RACR | RACR | SCREW |
