In today’s manufacturing industry, fiber laser cutting machines have become an essential tool for metal processing. Among them, the 2kW fiber laser cutting machine stands out for its balance of power, efficiency, and cost-effectiveness. But how exactly does it work, and why do so many workshops rely on it?   1. Principle of Laser Generation   Light Source: A fiber optic cable doped with ytterbium or other rare earth elements is used as the gain medium. A semiconductor pump source (such as a diode laser) excites the rare earth ions within the fiber, causing high-energy level transitions and releasing light of a specific wavelength (typically near-infrared light at 1070–1080 nm). Fiber Amplifier:   The laser is repeatedly reflected and amplified within the flexible fiber, forming a high-power density, high-beam-quality continuous or pulsed laser beam.   2. Laser Transmission and Focusing   Fiber Transmission:   The laser is transmitted through the flexible fiber to the cutting head, eliminating the need for complex mirror systems (unlike CO₂ lasers), resulting in minimal energy loss (<5%) and suitability for long-distance transmission. Focusing System:   Collimating lenses and focusing lenses (typically aspherical lenses) within the cutting head focus the laser beam into an extremely small spot (diameter approximately 0.01–0.1 mm), achieving power densities of 10⁶–10⁸ W/cm².   3. Material Cutting Mechanism Main physical processes in metal cutting: Absorption and Heating: Metal surfaces have high absorption rates for fiber laser wavelengths (especially for highly reflective materials like copper and aluminum; anti-reflective coatings can further enhance efficiency). Light energy is absorbed by electrons and converted into thermal energy, causing the local temperature of the material to instantly rise to its melting point or boiling point (e.g., approximately 1500°C for steel). Melting and vaporization:   Melting cutting (suitable for carbon steel, stainless steel): Laser energy melts the material, and auxiliary gases (such as nitrogen, oxygen) blow away the molten metal.   Sublimation cutting (suitable for thin sheets or high-precision requirements): The laser directly vaporizes the material without requiring auxiliary gases (such as extremely thin metals or non-metals). Role of auxiliary gases:   Oxygen (O₂): Reacts exothermically with molten metal (oxidation), accelerating cutting and improving the quality of carbon steel cut surfaces, but may produce an oxide layer.   Nitrogen (N₂): Inert protection, preventing oxidation, suitable for materials requiring clean cuts such as stainless steel and aluminum.   Formation of the cut seam:   The laser beam moves relative to the material (controlled by a CNC system) to form a continuous cut seam. Dynamic adjustment of the focal position (e.g., automatic focusing cutting head) to accommodate different material thicknesses.   4. CNC System and Motion Control CNC Control: Pre-set cutting paths (e.g., DXF files) are converted by a computer into mechanical motion commands, driving servo motors to control the movement of the cutting head or worktable (X/Y/Z axes). Dynamic Precision:   High-precision guideways and linear motors ensure positioning accuracy (±0.05mm) at cutting speeds of up to 50m/min.     5. Advantages and Limitations of 2kW Power   Advantages:   Can cut thicker materials (e.g., carbon steel ≤20mm, stainless steel ≤12mm, aluminum ≤10mm).   Faster speed (30%–50% faster than a 1kW laser machine). Lower energy consumption (electro-optical conversion efficiency of 30%–50%, significantly higher than CO₂ lasers at 10%).   Limitations:   Special processing is required for highly reflective materials (e.g., copper, gold) (e.g., adjusting pulse frequency).   Extremely thick materials (e.g., carbon steel >25mm) may require multiple cuts or alternative methods such as plasma/flame cutting.   6. Key components and technologies   Fiber laser: 2kW single-mode or multi-mode fiber lasers from brands such as IPG and SPI.   Cutting head: Brands such as Precitec and Raytools, including protective lenses, gas nozzles, and capacitive height adjustment systems.   Cooling system: Water-cooled units maintain stable laser temperature (±1°C).   Dust removal system: Ventilation or filtration devices handle cutting fumes.   7. Typical Application Scenarios   Industries: Sheet metal processing, automotive parts, aerospace, electronic enclosures, etc.   Materials: Carbon steel, stainless steel, aluminum alloy, brass, titanium alloy, etc.   Processing types: Flat cutting, drilling, and irregular contour cutting. Translated with DeepL.com (free version) Summary： The 2kW fiber laser cutting machine uses high-energy fiber laser beams, precision optical systems, and CNC technology to achieve efficient, high-precision cutting of metal materials. Its core advantages lie in its high power density, low energy consumption, and low maintenance costs, making it particularly suitable for processing medium-thickness metal plates. In practical applications, the power, focal position, and auxiliary gas type must be adjusted according to the material characteristics to optimize cutting quality.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

When operating a press brake, corner bending is one of the most challenging processes. Compared with straight-line bending, corners place higher demands on precision, tooling, and operator experience. If not handled correctly, several problems may occur that affect both product quality and production efficiency.   1. Angle deviation (inaccurate Angle） Reason: Improper mold selection (such as the V-groove width not matching the material thickness). The excessive opening of the lower die leads to an increase in springback. Insufficient pressure or too fast bending speed. Material properties (such as obvious rebound of stainless steel and high-carbon steel). Solution: Adjust the pressure and compensation Angle (correct the rebound through trial folding). Select an appropriate mold and reduce the bending speed to increase plastic deformation. 2. Bending dimensional error (length or position deviation) Reason: Inaccurate positioning of the back gauge or mechanical wear. The boards are placed unevenly or the reference surfaces are not close together. Programming data input errors (such as bending sequence, size). Solution: Calibrate the rear stopper and check the accuracy of the servo system. Use laser detection or clamp-assisted positioning.   3. The bent line is twisted or uneven The reason is that the burrs on the edge of the sheet were not treated, resulting in uneven stress during bending. Mold wear or misalignment of the upper and lower molds (parallelism deviation). Internal stress of materials (such as unannealed cold-rolled plates). Solution: Deburr and ensure the board is smooth. Adjust the parallelism of the mold and replace it if necessary.   4. Indentations or scratches on the surface of the workpiece Reason: There are impurities or damages on the surface of the mold. The protective film of the material was not removed or the mold was not cleaned adequately. Excessive bending pressure causes metal adhesion. Solution: Clean the mold and use a dedicated polishing mold or PE protective film. Adjust the pressure or switch to a soft mold (such as polyurethane).   5. Springback Reason: The material has a high elastic modulus (such as aluminum and stainless steel). The bending radius is too large or the Angle is too small. Solution: Adopt the compensation method (excessive bending). Use a mold with correction function or add a flattening step.   6. Bending cracks or fractures Reason: Poor ductility of the material (such as hard aluminum alloy, high carbon steel). The bending direction is parallel to the rolling direction of the material. The bending radius is too small (lower than the minimum bending radius). Solution: Increase the bending radius or anneal the material. Adjust the bending direction (perpendicular to the rolling direction).   7. Damage to equipment or molds Reason: Overloading bending (such as thickness exceeding the die's load-bearing range). The mold collided or was not fixed correctly. Solution: Operate strictly in accordance with the equipment tonnage and mold specifications. Regularly check the tightness of the mold.   8. Cumulative error of multiple bends Reason: Multiple positioning causes the reference to shift. The bending sequence is unreasonable (for example, bending at a large Angle first and then interfering with a small Angle). Solution: Optimize the bending sequence (from inside to outside, from complex to simple). Use multi-axis rear stoppers or robot-assisted positioning.   9. Warping or deformation of the sheet Reason: Uneven distribution of bending force (such as no support in the middle of long plates). Release of residual stress in materials. Solution: Add support blocks or bend in multiple steps. Select the material after stress release. 10. Operational safety issues Risk: Hand pinching (near the mold area). The sheet rebounds or slips off. Protection: Use safety devices such as gratings and two-hand start buttons. Train operators to standardize procedures.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

The CNC Panel Bender Machine is widely recognized for its ability to deliver precise, efficient, and repeatable bending operations, making it an essential tool in modern sheet metal fabrication. Its unique automated bending process is ideal for handling complex shapes, large panels, and small batch production with minimal manual intervention. From industrial enclosures and cabinet manufacturing to appliance panels and architectural components, the CNC panel bender serves a diverse range of industries. In this article, we will outline the typical application scenarios where this advanced machine demonstrates its full potential.   1.Manufacturing of electrical cabinets and distribution boxes Application requirements Quickly process side panels, door panels and installation brackets of cabinets of different sizes. The bending accuracy (±0.1mm) must be guaranteed to fit the assembly. Advantages of Panel Bender: Mold-free: Directly bend with universal grippers, suitable for multi-variety and small-batch orders (such as customized cabinets). High-efficiency linkage: Automatically complete multi-sided bending (such as one-time forming of the box body), which is 50% faster than traditional bending machines.   2. Elevator and building decorative panels Application requirements Precision bending of stainless steel/aluminum elevator car wall panels and decorative lines. Processing of complex shapes (such as arc-shaped gradient bending). Advantages of Panel Bender: High-precision surface bending: Achieve gradual Angle changes (such as R-angle transitions) through a numerical control system. No surface damage: No mold contact, avoiding the indentation problem of traditional bending.   3. Manufacturing of automotive parts Application requirements Bending of lightweight aluminum plates for body structural components (such as battery trays and brackets). High consistency requirements (tolerance of new energy vehicle components ±0.2mm). Advantages of Panel Bender: Aluminum plate adaptability: Automatic rebound compensation, solving the problem of cracking when aluminum materials are bent. In-line production: It forms a flexible production line with laser cutting machines to achieve seamless connection between "cutting and bending".   4. Household appliances and consumer electronics Application requirements Batch bending of refrigerator/washing machine casings and metal casings. Precision processing of thin plates (0.5 to 1.5mm) to avoid deformation. Advantages of Panel Bender: Thin plate stability: Servo pressure control, avoiding indentation or deformation in traditional bending. Quick model change: Switch between different product programs within 5 minutes (such as from refrigerator door panel to washing machine panel).   5. Ventilation ducts and HVAC equipment Application requirements Multi-sided bending of air duct flanges and connecting parts. Large-sized bending of stainless steel/galvanized sheets (length ≥4m). Advantages of Panel Bender: Long sheet processing: Supports bending of 6-meter-long sheets (traditional equipment requires segmented processing). Welding-free design: By bending to replace part of the welding process, deformation is reduced.   6. Metal furniture and display stands Application requirements Irregular bending of shelves, display cabinets and metal table legs. Small-batch customized production (such as art-shaped furniture). Advantages of Panel Bender: Flexible design: Directly import complex bending paths through CAD. Low-cost trial production: No mold opening required, suitable for rapid sample verification.   7. New energy and energy storage equipment Application requirements Aluminum/steel structural components for photovoltaic brackets and energy storage cabinets. Corrosion resistance requirements (such as bending of aluminum-magnesium coated plates). Advantages of Panel Bender: Material compatibility: Special claw treatment prevents coating damage. High-intensity bending: Precise control of servo pressure ensures the load-bearing performance of structural components.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

The CNC Punch Laser Combined Machine represents a breakthrough in modern sheet metal processing, integrating the high-speed precision of CNC punching with the flexibility and cutting quality of laser technology. This hybrid solution allows manufacturers to perform punching, forming, and complex laser cutting in a single setup, significantly improving productivity and reducing material handling time. With advanced automation, intelligent control systems, and versatile processing capabilities, it delivers exceptional efficiency, accuracy, and cost-effectiveness for a wide range of industrial applications. In this blog, we will explore the key technical highlights that make this combined machine a game-changer in the sheet metal industry.   1. Efficient collaborative processing (seamless switching between stamping and laser) Automatic switching technology Through the automatic switching of the turret mold library (such as 16 stations) and the laser cutting head, continuous processing of "punching → cutting → forming" is achieved without the need for secondary clamping. Time-saving: For instance, when processing the panels of electrical cabinets, after stamping the ventilation holes, the contour is directly laser-cut, which increases efficiency by 30% to 50%. Composite process path optimization CAM software (such as TruTops Boost) automatically plans the optimal processing sequence to avoid repetitive positioning errors.   2. Ultra-high precision (within ±0.1mm) Laser compensation for stamping error Stamping may cause material deformation or burrs, while laser cutting can precisely trim the edges (such as removing stamping burrs). Dynamic focus control The laser head is equipped with Z-axis auto-focusing, adapting to materials of different thicknesses (0.5 to 20mm). High-rigidity machine tool structure The cast iron bed and linear guide rails are adopted to reduce vibration and ensure the positioning consistency of laser cutting and stamping.   3. Multi-functional integration (One machine can complete multiple processes Stamping function Supports punching, tapping, embossing, blind forming, etc. Laser function Fiber lasers (1 to 6kW) can cut carbon steel, stainless steel, aluminum and copper, and can also perform precise engraving. Special process expansion Some models support the integration of bending units, achieving a three-in-one combination of stamping, laser and bending.   4. Intelligence and automation Intelligent material arrangement system AI algorithms optimize the utilization rate of sheet materials (such as automatically nesting punching and cutting paths to reduce waste). Internet of Things (IoT) remote monitoring Real-time monitoring of mold life, laser status, and energy consumption data, predictive maintenance reduces downtime. Automatic loading and unloading options Combined with robots or material warehouses, it can achieve 24-hour unmanned production.   5. Energy-saving and environmentally friendly design Hybrid power stamping Servo motor-driven stamping saves 40% energy compared to traditional hydraulic presses. Laser sleep mode It automatically reduces power consumption when in standby mode. Dust removal system Integrated pulse dust removal reduces the pollution of laser cutting smoke and dust.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

What are the application scenarios of CNC Press Brake Machine?   1.Metal Fabrication & Sheet Metal Chassis/cabinet manufacturing: such as electrical control cabinets, server cabinets, industrial equipment enclosures, etc. Ventilation ducts (HVAC) : Used for sheet metal bending of air conditioning ducts, smoke exhaust ducts, etc. Metal doors and Windows/curtain walls: Precise bending of aluminum alloy or stainless steel frames for construction.   2. Automotive & Transportation Body components: door brackets, chassis structural parts, exhaust pipes, etc. New energy vehicle battery box: Lightweight bending of high-strength aluminum plates. Rail transit components: Metal decorative panels or structural parts for high-speed rail/metro carriages.   3. Aerospace Aircraft structural components: wing ribs, bulkhead brackets and other high-strength alloy parts. Engine components: Complex multi-angle bending of high-temperature resistant metals. Precision forming of titanium alloy or composite materials for spacecraft casings.   4. Electronics & Appliances Electronic product casings: metal bases for laptops, panels for smart home devices. Internal brackets for electrical appliances: compressor brackets for refrigerators, metal inner linings for microwave ovens. Heat sink: High-density fins are bent to optimize heat dissipation performance.   5. Energy & Power Solar bracket: Batch bending of photovoltaic panel support structures. Transformer box: The metal casing of large power equipment. Nuclear power equipment: Safe forming of corrosion-resistant stainless steel components.   6. Industrial Machinery Agricultural machinery: Sheet metal covers for harvesters, tractor parts. Construction machinery: excavator cab frame, hydraulic pipe fittings. Food machinery: Stainless steel conveyor belt brackets, sanitary-grade containers.   7. Medical Equipment Surgical instruments: Precise bending of stainless steel forceps and tweezers. Medical bed/trolley: Cleaning and bending of antibacterial metal frames. Imaging equipment housing: Protective covers for MRI or CT scanners.   8. Architecture & Decoration Metal artworks: Creative bending of sculptures and decorative lines. Parametric design and processing of special-shaped aluminum plates for building curtain walls. Furniture design: Personalized forming of modern metal tables and chairs.   9. Defense & Military Armored vehicle components: Special Angle bending of bulletproof steel plates. Weapon stand: High-stability metal structure processing. Drone frame: Lightweight aluminum alloy fuselage formed.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

1. Sheet metal processing industry (1) Chassis and cabinet manufacturing Application: Production of electrical control cabinets, server cabinets, distribution boxes, etc. Advantages It can quickly bend metal plates of different sizes (such as stainless steel and aluminum plates) to ensure high-precision splicing. Case: Electrical equipment suppliers such as Schneider and Siemens have adopted CNC Panel Bender to enhance the production efficiency of cabinets. (2) Ventilation ducts and air conditioning components Application: Manufacturing air ducts, flanges, air conditioning casings, etc. Advantages Supports complex bending angles (such as Z-shaped and U-shaped grooves), reduces welding requirements and enhances sealing performance.   2. Construction and decoration industry Metal curtain walls and ceilings Application: Architectural decorative parts made of aluminum plates and stainless steel plates (such as curved surface modeling, column cladding plates). Advantages It can process large-sized plates (such as 6m long), reduce seams and enhance the aesthetic appeal. (2) Elevators and automatic doors Application: Metal cladding for elevator cabins and automatic doors. Advantages High-precision bending ensures a seamless assembly and reduces subsequent adjustments.   3. Automobiles and Rail Transit (1) Body and components Application: Truck cabs, new energy battery boxes, body panels. Advantages It is adaptable to high-strength steel, aluminum alloy and other materials, meeting the demand for lightweighting. (2) Interior decoration of high-speed railways and subways Application: Seat brackets, luggage racks, compartment partitions. Advantages It has high consistency during mass production and meets the strict standards of rail transit.   4. Home appliance and electronics industry (1) Household appliance shells Application: Refrigerator side panels, washing machine panels, oven shells. Advantages Flexible production enables rapid switching of bending programs for different models. (2) Structural components of electronic equipment Application: 5G base station enclosures, industrial computer cases. Advantages High-precision bending (±0.1mm) ensures electromagnetic shielding performance.   5. Aerospace and military Industry Aircraft components Application: Aviation seat frames, luggage compartment components. Advantages It can process special materials such as titanium alloy and carbon steel to meet high-strength requirements. (2) Military equipment box bodies Application: Missile launch boxes, enclosures of field communication equipment. Advantages Adapt to the structural stability requirements in extreme environments.   6. Other special applications Medical devices Application: Operating table stents, medical equipment shells (such as CT machine protective covers). Advantages Seamless bending to prevent surface damage that could lead to bacterial growth. (2) Furniture and display equipment Application: Metal office desks, display stands, shelves. Advantages Support creative design (such as arc-shaped bending) to enhance the added value of products.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

1. Upgrade to intelligence and automation AI process optimization Through real-time analysis of cutting parameters (power, speed, air pressure, etc.) by artificial intelligence, automatic adjustments are made to reduce the scrap rate and adapt to different types of pipes (such as stainless steel, aluminum alloy, copper pipes). For instance, the AI vision system automatically identifies pipe defects or deformations and dynamically corrects the cutting path. The entire process is fully unmanned Integrate automatic loading and unloading, sorting and packaging systems, and combine them with AGV/RGV logistics to achieve "dark factory" level automated production. Digital Twin and Remote Operation and Maintenance Through virtual simulation to preview the cutting process, remotely monitor the equipment status and predict faults (such as laser life warning). 2. High-power and ultrafast laser technology Higher power fiber laser (>30kW Improve the cutting efficiency of thick-walled tubes (such as carbon steel ≥50mm), reduce beveling errors at the same time, and replace some plasma/flame cutting scenarios. Challenge: It is necessary to address the control of thermal deformation and the stability of beam quality at high power. Ultrafast laser (picosecond/femtosecond) applications For precision medical tubes and thin-walled irregular-shaped tubes (such as cardiovascular stents), heat-affected zone cutting is achieved to reduce subsequent polishing processes. 3. Multi-axis linkage and complex processing capabilities Compound motion of 7 axes or more By adding a rotation axis (such as a swing head) and dynamic focus control, one-time cutting of three-dimensional curved surface pipes (such as automotive exhaust pipes and aerospace components) can be achieved. Online detection and real-time compensation Integrate laser ranging or 3D scanning to correct errors caused by pipe bending or fixture offset in real time during the cutting process. 4. Material adaptability expansion Cutting of composite pipes Break through the technical bottlenecks of difficult-to-process materials such as coated pipes (like galvanized pipes) and carbon fiber composite pipes, and reduce delamination or ablation. Solution: Pulse-modulated laser + auxiliary gas optimization (such as nitrogen/helium mixture). Pretreatment before welding dissimilar metal pipes Through the integrated process of laser cleaning and cutting, high-cleanliness cuts are provided for the welding of dissimilar metal tubes such as copper-aluminum. 5. Green Manufacturing and Sustainable Development Energy consumption optimization By adopting variable frequency drive and energy recovery system, the unit energy consumption of the fiber laser pipe cutting machine is reduced (currently about 3-5kW·h/ hour). Environmentally friendly process substitution Reduce the generation of oil stains and dust in traditional cutting, for instance, by replacing wet dust removal with dry cutting. Improvement in material utilization rate By using AI layout software, the utilization rate of pipes has been increased from 70% to over 90%, reducing waste. Prospects for Future Application scenarios New energy vehicles: Efficient cutting of battery pack structure tubes and hydrogen energy storage tanks. Building industrialization: Rapid processing of complex steel structure pipes in prefabricated buildings. Precision cutting of titanium alloy pressure-resistant tubes for space and deep-sea equipment. Summary： The future breakthroughs of fiber laser pipe cutting machines will revolve around "smarter, more precise and greener", while domestic substitution and technological integration (such as AI+ laser) will become key driving forces. Enterprises need to pay attention to the customized demands in high value-added fields (such as healthcare and aerospace) to seize market opportunities. If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

1.Enhance processing efficiency and production capacity High-speed batch cutting Hydraulic drive provides stable pressure (typically 100-500 tons), enabling rapid shearing of metal plates with thicknesses ranging from 1mm to 25mm (such as steel plates, stainless steel, and aluminum plates), with an efficiency increase of 30% to 50% compared to traditional mechanical shearing machines. Typical applications: Large-scale production scenarios such as automotive sheet metal parts, electrical cabinets, and building curtain walls. Automated integration Equipped with an automatic feeding system and stacking devices, it can achieve unmanned continuous production, reduce manual intervention, and increase production capacity by up to 200%.   2. Ensure processing accuracy and quality High-precision shearing The adoption of a hydraulic synchronous system and a CNC rear stopper (with an accuracy of ±0.05mm) ensures a smooth and burr-free cut, reducing the need for secondary processing (such as grinding). Compared with traditional shearing methods, material waste is reduced by 15% to 20% (which is particularly crucial for high-priced materials such as stainless steel and titanium alloys). Highly adaptable knife edge design The replaceable upper and lower blades adapt to different material thicknesses and hardnesses, extending the tool's lifespan.   3. Reduce manufacturing costs Energy conservation and maintenance costs Modern hydraulic systems are equipped with variable pumps, which are 20% to 30% more energy-efficient than traditional fixed pumps. The structure is simple, the failure rate is low, and the maintenance cost is only 1/3 to 1/5 of that of a laser cutting machine. Optimization of material utilization rate The optimal layout of sheet materials can be achieved through numerical control programming, with a utilization rate of over 90% (manual layout is usually only 70%-80%).   4. Expand the range of processing capabilities Treatment of thick plates and special materials It can shear high-strength steel and composite materials, solving the efficiency bottleneck of laser cutting on thick plates (>12mm). Some models are equipped with an angle-adjustable tool rest to achieve bevel shearing and meet the requirements of welding bevels. Flexible production support Quick mold replacement (only 10 minutes for some models) is suitable for multi-variety and small-batch orders, and the cost is 80% lower than that of stamping molds.   5. Safety and operational convenience Multiple safety protections The photoelectric protection device and dual-hand start buttons comply with CE and OSHA safety standards, and the accident rate is 90% lower than that of traditional mechanical shearing machines. Human-computer interaction optimization The touch screen numerical control system supports graphical programming, and the operator training period is shortened to 1-3 days. Summary： The hydraulic guillotine shearing machine, with its features of high efficiency, low cost and high reliability, has become a "backbone equipment" in the basic processing links of the manufacturing industry. It is especially suitable for production scenarios that require large-scale linear cutting, thick plate processing, and cost-sensitive production, and is an important supplement to advanced technologies such as laser cutting. With the popularization of intelligent and energy-saving technologies, their value will be further released. If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

1.Supply of raw materials and core components Key link Metal materials Sheet metal raw materials such as steel plates and aluminum alloys. Value-added point: The strength and ductility of the material directly affect the bending accuracy and the service life of the mold. Core components Hydraulic/servo system → Determines the power and energy efficiency of the machine. The CNC control system → affects programming flexibility and operational accuracy. Tooling (Wila, Rocca) → Specialized tooling (such as V-type, R-type) to meet complex bending requirements. Challenge High-end hydraulic systems and CNC controllers rely on imports (Chinese manufacturers are accelerating domestic substitution). 2. Design and manufacturing Key link Mechanical structure design The rigidity of the frame and the accuracy of the guide rails affect long-term stability. Value-added point: Finite element analysis (FEA) optimizes the structure and reduces deformation. Intelligent function integration Laser Angle detection, AI rebound compensation. Value-added points: Reduce trial-and-error costs and increase the first-article pass rate. Cost distribution Mechanical structure (40%), control system (30%), hydraulic/servo system (20%), others (10%).   3. Distribution and after-sales service Key link Sales channels Direct selling (high-end brands such as TRUMPF), agents (emerging markets), online platforms. Value-added points: Offer trial use and technical training (such as operation courses of the Delem control system).   After-sales service Remote diagnosis (IoT modules), rapid spare parts supply (molds, hydraulic valves). Value-added point: Service contracts (annual fee system) contribute 20-30% of the manufacturer's profits. Regional differences The European and American markets prefer all-inclusive services, while the Asian market pays more attention to cost performance and response speed.   4. Terminal Applications and User Value Main application fields Sheet metal processing: chassis, cabinets (batch consistency required). Automobile manufacturing: Body structural components (high-precision requirements). Aerospace: Lightweight components (special material bending). Core user demands Small-batch production: Quick mold change. Mass automation: Robot integration.   5. Auxiliary value chain links Software and digital tools Offline programming software (Radan, AutoPOL) → Reduce machine idle time. Simulation (such as AutoForm) → Predict material rebound and optimize processes. Third-party service provider Mold customization (local small manufacturers meet non-standard requirements). Technical training (community colleges, manufacturer certification courses). The trend of value chain optimization Upstream integration Leading manufacturers develop their own control systems to reduce external reliance. Downstream expansion Provide "Bending-as-a-Service" and charge based on the duration of use. Green value chain Electric servo bending machines (such as Salvagnini P4) replace hydraulic models, reducing energy consumption by over 30%. Summary： In the value chain of CNC Press Brake: High-profit zone: Control system design, intelligent software, after-sales service. Bottleneck links: Localization of core components (Chinese manufacturers are making breakthroughs), shortage of skilled operators. Future opportunities： Leasing model (lowering the entry threshold for small and medium-sized enterprises). AI+IoT enables predictive maintenance (such as predicting hydraulic failures through vibration data). By optimizing the value chain, manufacturers can transform from "equipment suppliers" to "solution providers" and gain higher added value   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

I. Mechanical Injuries (the most common and diverse forms) The upper and lower dies squeeze and hurt the hand Dangerous scenario: When positioning or picking up and placing small workpieces after adjustment, if the hand accidentally enters the closed area of the mold (there is a risk of cutting if the stroke is ≥10mm). Typical case: Improper gesture when bending small parts (Figure 2), the finger was caught between the upper die and the workpiece, resulting in a comminuted fracture. Protection: Mandatory use of photoelectric protection devices (light curtains), automatic shutdown when hands enter the hazardous area. Physical isolation barriers are installed in the mold area. 2. Workpiece impact and dropping Risk of double-person operation: When bending large items, they need to be lifted in coordination. If the workpiece becomes unstable and falls, it may hit the foot or head (Figure 1). The burrs on the edge scratched the arm. Material stacking risk: The workpiece to be processed is stacked too high and overturns, or is scratched by sharp corners when turned around. Protection: Heavy items require hoisting equipment. Wear anti-crush shoes and safety helmets; The workpiece is reprocessed after deburring. 3. Accidents during mold loading and unloading Loose fastening bolts of the upper mold cause the mold to fall, or the lower mold is not padded with support wood, resulting in a rolling accident. Protection: Operate strictly after locking the machine (LOTO program); Anti-fall brackets are designed in the mold installation area. Ii. Electrical Injuries (with the highest fatality rate) 1. Electrical leakage caused by illegal renovation Non-standard circuit modification (such as direct connection of the neutral wire to the PE terminal) causes the equipment casing to carry a 220V voltage, significantly increasing the risk of electric shock. Protection: Comply with the national standard "single power connection" principle; A third-party electrical safety certification is required after the renovation. 2. Aging of circuits and short circuits Cable damage and negative pressure ventilation in the electrical cabinet drawing in cutting fluid/dust (as shown in the illustration) can cause an internal short circuit or fire in the electrical cabinet. Protection: The protection grade of the electrical cabinet is ≥IP54; Inspect the insulation condition of the lines every day; Leakage protection devices should be installed for wet zone operations. 3. Grounding failure of the equipment Poor grounding causes the metal frame to become electrified. During the rainy season or in damp workshops, it is easy to form an electric shock circuit. Protection: Test the grounding resistance (≤4Ω) weekly; Insulating rubber pads are laid on the operation console.   Iii. Parameter Errors and Mold Out-of-control 1. The pressure setting exceeds the limit The pressure suddenly increased beyond the limit value of the mold (such as setting a 300T parameter for a 200T press), causing the mold to crack and fragments to fly. Protection: Hierarchical management of parameter permissions; The system has a built-in pressure-mold matching database. 2. Overheating of the mold and lack of maintenance Continuous bending of thick stainless steel plates causes the mold temperature to rise by more than 150℃, and the annealing deformation of the material leads to mold jamming. Protection: Early warning by mold temperature control sensor; Cool and lubricate every 2 hours.   Iv. Human and Environmental Factors 1. Collaboration failure The foot switch operated by two people is not synchronized: When one person steps on it, the other is still adjusting the workpiece, causing the workpiece to shift and injure the lower jaw (Figure 3). Protection: Enable the "Double Confirmation" startup program (two people press keys simultaneously); Train collaborative gesture commands. 2. Fatigue and distraction When working in consecutive shifts for more than 4 hours, the rate of accidental button touches increases by 40%. Wearing gloves when handling small items makes it easy to get caught in. Protection: Mandatory rotational rest every 90 minutes; Do not use gloves when bending small items. 3. Environmental hazards After slipping due to the oil stains on the ground, my hand fell into the mold area. Insufficient light misjudges the positioning of the workpiece. Protection: 5S management (especially immediate cleaning of oil stains); The illuminance in the operation area is ≥300 lux. Summary： The safety of bending machines requires equal emphasis on technical protection (hardware) and behavioral management (software). Urgent priority: Photoelectric protection + electrical compliance transformation to avoid immediate life-threatening risks; Long-term management: Each shift's "Hazard Source Board" (Figure 4) indicates the risk points of the day, and combines the SHARP analysis method to quantify the nodes of human error. Operators must keep in mind: "Do not put your hands in the mold area, keep your eyes on the workpiece, and do not take chances" - any negligence of 0.1 seconds may cause irreversible damage.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

The CNC bending machine is one of the core equipment in the field of metal sheet processing. With its high precision, high efficiency, flexibility and repeatability, it is widely used in modern manufacturing. Almost all industries involving the forming and processing of metal sheets will use it. The following are some major application industries:   1. Sheet metal manufacturing and processing industry Core application fields. This is the most fundamental and widespread application scenario of CNC bending machines. Processing objects: Metal plates of various specifications and materials (such as cold-rolled plates, galvanized plates, aluminum plates, stainless steel plates, copper plates, etc.). Typical products: chassis and cabinets, various brackets, shells, covers, trays, panels, ventilation ducts, connectors, etc.   2. Chassis and electrical cabinet industry: Highly dependent. It is used for manufacturing the enclosures, door panels, internal mounting panels, guide rails, etc. of server cabinets, network cabinets, distribution cabinets, control cabinets, electrical switch cabinets, industrial control boxes, etc. High requirements are placed on precision and consistency.   3. Elevator Industry: It is used for manufacturing wall panels, door panels, top panels, floors, control box panels, various brackets, etc. of elevator cars.   4. Automobile and Parts Manufacturing: Body and structural components: doors, inner panels of the hood, seat frames, chassis brackets, crossbeams, longitudinal beams, battery boxes (for new energy vehicles), etc. Components: exhaust pipe, muffler, fuel tank, various brackets (engine brackets, sensor brackets, etc.), interior parts frame, etc.   5. Aerospace It is used for manufacturing structural components, brackets, fairings, control panels, instrument panel frames, seat parts, etc. inside aircraft or spacecraft. It has extremely high requirements for precision, materials (such as high-strength aluminum alloys and titanium alloys) and processes.   6. Home Appliance Industry Enclosures and structural components: Metal enclosures, inner tanks, brackets, door bodies, panels, etc. of household appliances such as refrigerators, washing machines, air conditioners (indoor and outdoor units), ovens, microwave ovens, water heaters, range hoods, and stoves.   7. Architectural Decoration and Curtain Wall Industry: It is used for manufacturing metal curtain wall panels (aluminum single panels, composite aluminum panels), ceilings, metal roof panels, column cladding panels, decorative lines, railings and handrails, door and window frames, canopy brackets, etc.   8. Construction Machinery and Agricultural Machinery: It is used for manufacturing cabs, body panels (side panels, engine hoods), fuel tanks, toolboxes, various structural supports and connecting parts for equipment such as excavators, loaders, cranes, tractors and harvesters.   9. Communication equipment industry: Manufacture base station cabinets, antenna brackets, filter housings, server chassis, switch chassis, etc.   10. Medical devices and laboratory equipment: Manufacturing medical bed frames, trolleys, instrument cabinets, disinfection equipment casings, laboratory fume hoods, laboratory bench frames, instrument casings, etc. High cleanliness and precision are usually required.   11. Furniture Industry (Metal Furniture) : Manufacture metal office desks, filing cabinets, shelves, display stands, metal chair frames, metal bed frames, etc.   12. Lighting Industry: We manufacture street lamp poles, garden lamp bodies, large floodlight housings, industrial and mining lamp housings, LED lamp heat sink housings, etc.   13. Rail Transit Manufacture interior decorative panels (wall panels, ceiling panels), seat frames, equipment boxes, ventilation duct components, etc. for trains, subways and trams.   In summary, the industry characteristics of the application of CNC bending machines include Involving the forming of metal sheets: This is the most fundamental prerequisite. High precision and consistency are required: Numerical control technology ensures the accuracy of repeated processing. The product structure is relatively complex: it requires multiple bending processes to complete. Pursuing production efficiency and flexibility: Products can be quickly programmed and switched to adapt to small-batch and multi-variety production. There are requirements for structural strength and appearance: Bending can provide good structural strength and a smooth and beautiful appearance.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

Core value-driven: Precision leap: Eliminate human errors, achieve extremely high dimensional consistency, and ensure perfect alignment in subsequent bending, welding and other processes. Efficiency doubling: Automated positioning, rapid shearing, and continuous operation significantly reduce the processing time of individual pieces and the overall production cycle. Material conservation: Precise cutting minimizes waste to the greatest extent, and optimized layout functions can further enhance material utilization. Reduce labor intensity: The operation is more convenient and effortless, reducing the reliance on highly skilled workers. Enhancing safety: Multiple safety safeguard measures significantly reduce the risk of work-related injuries. Improve cut quality: Precise gap control and stable shear force result in smooth, vertical, and burr-free (or minimally burr-free) cuts. Flexible production: Quickly switch between different product programs to meet the demands of small-batch and diversified production.   The CNC shearing machine is the first precise process in the metal sheet processing of many industries: Sheet metal processing factory: chassis and cabinets, control cabinets, ventilation ducts, etc. Elevator manufacturing: car wall panels, door panels, structural components. Construction machinery: cabs, covering parts, structural parts and plates. Power equipment: Switch cabinets, transformer boxes. Kitchenware and equipment: Stainless steel countertops, cabinets. Architectural decoration: curtain wall panels, metal decorative pieces. Automobiles and auto parts: body parts, brackets, chassis parts. Home appliance manufacturing: shells, back plates, brackets. Rail transit: Components inside and outside the carriages. New energy (wind power, photovoltaic) : brackets, structural component plates.   Select the key considerations: Shearing capacity: Maximum shearing length (determining the width of the plate that can be sheared), maximum shearing thickness (determining the thickness of the plate that can be sheared, with varying capabilities for different materials such as Q235 steel, stainless steel, aluminum, etc.). Throat depth: Affects the width range of the sheared sheet. Rear stopper accuracy and speed: positioning accuracy (±mm value) and moving speed. Blade clearance adjustment method: automatic/manual, adjustment accuracy. Overall structure and rigidity: The quality of the welded frame and the materials of key components directly affect stability and service life. Safety configuration level: safety light curtain level, whether it is equipped with safety fences, etc. Brand reputation and after-sales service: Of vital importance, they are related to the long-term stable operation of the equipment. If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088
