I. Mechanical Injuries (the most common and diverse forms) The upper and lower dies squeeze and hurt the hand Dangerous scenario: When positioning or picking up and placing small workpieces after adjustment, if the hand accidentally enters the closed area of the mold (there is a risk of cutting if the stroke is ≥10mm). Typical case: Improper gesture when bending small parts (Figure 2), the finger was caught between the upper die and the workpiece, resulting in a comminuted fracture. Protection: Mandatory use of photoelectric protection devices (light curtains), automatic shutdown when hands enter the hazardous area. Physical isolation barriers are installed in the mold area. 2. Workpiece impact and dropping Risk of double-person operation: When bending large items, they need to be lifted in coordination. If the workpiece becomes unstable and falls, it may hit the foot or head (Figure 1). The burrs on the edge scratched the arm. Material stacking risk: The workpiece to be processed is stacked too high and overturns, or is scratched by sharp corners when turned around. Protection: Heavy items require hoisting equipment. Wear anti-crush shoes and safety helmets; The workpiece is reprocessed after deburring. 3. Accidents during mold loading and unloading Loose fastening bolts of the upper mold cause the mold to fall, or the lower mold is not padded with support wood, resulting in a rolling accident. Protection: Operate strictly after locking the machine (LOTO program); Anti-fall brackets are designed in the mold installation area. Ii. Electrical Injuries (with the highest fatality rate) 1. Electrical leakage caused by illegal renovation Non-standard circuit modification (such as direct connection of the neutral wire to the PE terminal) causes the equipment casing to carry a 220V voltage, significantly increasing the risk of electric shock. Protection: Comply with the national standard "single power connection" principle; A third-party electrical safety certification is required after the renovation. 2. Aging of circuits and short circuits Cable damage and negative pressure ventilation in the electrical cabinet drawing in cutting fluid/dust (as shown in the illustration) can cause an internal short circuit or fire in the electrical cabinet. Protection: The protection grade of the electrical cabinet is ≥IP54; Inspect the insulation condition of the lines every day; Leakage protection devices should be installed for wet zone operations. 3. Grounding failure of the equipment Poor grounding causes the metal frame to become electrified. During the rainy season or in damp workshops, it is easy to form an electric shock circuit. Protection: Test the grounding resistance (≤4Ω) weekly; Insulating rubber pads are laid on the operation console.   Iii. Parameter Errors and Mold Out-of-control 1. The pressure setting exceeds the limit The pressure suddenly increased beyond the limit value of the mold (such as setting a 300T parameter for a 200T press), causing the mold to crack and fragments to fly. Protection: Hierarchical management of parameter permissions; The system has a built-in pressure-mold matching database. 2. Overheating of the mold and lack of maintenance Continuous bending of thick stainless steel plates causes the mold temperature to rise by more than 150℃, and the annealing deformation of the material leads to mold jamming. Protection: Early warning by mold temperature control sensor; Cool and lubricate every 2 hours.   Iv. Human and Environmental Factors 1. Collaboration failure The foot switch operated by two people is not synchronized: When one person steps on it, the other is still adjusting the workpiece, causing the workpiece to shift and injure the lower jaw (Figure 3). Protection: Enable the "Double Confirmation" startup program (two people press keys simultaneously); Train collaborative gesture commands. 2. Fatigue and distraction When working in consecutive shifts for more than 4 hours, the rate of accidental button touches increases by 40%. Wearing gloves when handling small items makes it easy to get caught in. Protection: Mandatory rotational rest every 90 minutes; Do not use gloves when bending small items. 3. Environmental hazards After slipping due to the oil stains on the ground, my hand fell into the mold area. Insufficient light misjudges the positioning of the workpiece. Protection: 5S management (especially immediate cleaning of oil stains); The illuminance in the operation area is ≥300 lux. Summary： The safety of bending machines requires equal emphasis on technical protection (hardware) and behavioral management (software). Urgent priority: Photoelectric protection + electrical compliance transformation to avoid immediate life-threatening risks; Long-term management: Each shift's "Hazard Source Board" (Figure 4) indicates the risk points of the day, and combines the SHARP analysis method to quantify the nodes of human error. Operators must keep in mind: "Do not put your hands in the mold area, keep your eyes on the workpiece, and do not take chances" - any negligence of 0.1 seconds may cause irreversible damage.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

The CNC bending machine is one of the core equipment in the field of metal sheet processing. With its high precision, high efficiency, flexibility and repeatability, it is widely used in modern manufacturing. Almost all industries involving the forming and processing of metal sheets will use it. The following are some major application industries:   1. Sheet metal manufacturing and processing industry Core application fields. This is the most fundamental and widespread application scenario of CNC bending machines. Processing objects: Metal plates of various specifications and materials (such as cold-rolled plates, galvanized plates, aluminum plates, stainless steel plates, copper plates, etc.). Typical products: chassis and cabinets, various brackets, shells, covers, trays, panels, ventilation ducts, connectors, etc.   2. Chassis and electrical cabinet industry: Highly dependent. It is used for manufacturing the enclosures, door panels, internal mounting panels, guide rails, etc. of server cabinets, network cabinets, distribution cabinets, control cabinets, electrical switch cabinets, industrial control boxes, etc. High requirements are placed on precision and consistency.   3. Elevator Industry: It is used for manufacturing wall panels, door panels, top panels, floors, control box panels, various brackets, etc. of elevator cars.   4. Automobile and Parts Manufacturing: Body and structural components: doors, inner panels of the hood, seat frames, chassis brackets, crossbeams, longitudinal beams, battery boxes (for new energy vehicles), etc. Components: exhaust pipe, muffler, fuel tank, various brackets (engine brackets, sensor brackets, etc.), interior parts frame, etc.   5. Aerospace It is used for manufacturing structural components, brackets, fairings, control panels, instrument panel frames, seat parts, etc. inside aircraft or spacecraft. It has extremely high requirements for precision, materials (such as high-strength aluminum alloys and titanium alloys) and processes.   6. Home Appliance Industry Enclosures and structural components: Metal enclosures, inner tanks, brackets, door bodies, panels, etc. of household appliances such as refrigerators, washing machines, air conditioners (indoor and outdoor units), ovens, microwave ovens, water heaters, range hoods, and stoves.   7. Architectural Decoration and Curtain Wall Industry: It is used for manufacturing metal curtain wall panels (aluminum single panels, composite aluminum panels), ceilings, metal roof panels, column cladding panels, decorative lines, railings and handrails, door and window frames, canopy brackets, etc.   8. Construction Machinery and Agricultural Machinery: It is used for manufacturing cabs, body panels (side panels, engine hoods), fuel tanks, toolboxes, various structural supports and connecting parts for equipment such as excavators, loaders, cranes, tractors and harvesters.   9. Communication equipment industry: Manufacture base station cabinets, antenna brackets, filter housings, server chassis, switch chassis, etc.   10. Medical devices and laboratory equipment: Manufacturing medical bed frames, trolleys, instrument cabinets, disinfection equipment casings, laboratory fume hoods, laboratory bench frames, instrument casings, etc. High cleanliness and precision are usually required.   11. Furniture Industry (Metal Furniture) : Manufacture metal office desks, filing cabinets, shelves, display stands, metal chair frames, metal bed frames, etc.   12. Lighting Industry: We manufacture street lamp poles, garden lamp bodies, large floodlight housings, industrial and mining lamp housings, LED lamp heat sink housings, etc.   13. Rail Transit Manufacture interior decorative panels (wall panels, ceiling panels), seat frames, equipment boxes, ventilation duct components, etc. for trains, subways and trams.   In summary, the industry characteristics of the application of CNC bending machines include Involving the forming of metal sheets: This is the most fundamental prerequisite. High precision and consistency are required: Numerical control technology ensures the accuracy of repeated processing. The product structure is relatively complex: it requires multiple bending processes to complete. Pursuing production efficiency and flexibility: Products can be quickly programmed and switched to adapt to small-batch and multi-variety production. There are requirements for structural strength and appearance: Bending can provide good structural strength and a smooth and beautiful appearance.   If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

1. Decreased Productivity: If you find that your old press brake machine is no longer able to meet your production demands and you're experiencing decreased productivity, it may be time to upgrade. Newer machines often feature advanced automation, faster cycle times, and improved accuracy, all of which can significantly increase productivity. 2. Outdated Technology: As technology advances, older press brake machines may become outdated. Newer machines are equipped with the latest features and capabilities, such as CNC controls, touch screen interfaces, and advanced software integration. Upgrading to a machine with more advanced technology can improve your workflow, programming capabilities, and overall efficiency. 3. High Maintenance and Repair Costs: If you find that you're frequently spending money on maintenance and expensive repairs for your old press brake machine, it might be more cost-effective to invest in a new one. Newer machines are often more reliable and require less frequent maintenance, reducing downtime and repair costs. 4. Safety Concerns: Safety should be a top priority in any manufacturing environment. Older press brake machines may lack the safety features and modern safeguards found in newer models. Investing in a machine with advanced safety features, such as laser guards, light curtains, or dual palm controls, can help protect your operators and ensure compliance with safety regulations. 5. Limited Functionality: If your current press brake machine is unable to perform certain bending applications or lacks the necessary features for your evolving production needs, it may be time to consider an upgrade. Newer machines often offer a wider range of bending capabilities, such as multi-axis backgauge systems, automatic tool changers, and adaptive bending technologies, allowing you to tackle complex jobs with ease. Ultimately, the decision to upgrade your old press brake machine will depend on your specific requirements, budget, and long-term goals. Consulting with industry experts and evaluating the benefits of newer technology can help you determine if upgrading is the right choice for your business. If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

The bending machine is the most expensive to install. Analytical sketch The operator must be fully familiar with its components. If the part has already been manufactured, it may not be necessary to modify the design, but ultimately the operator must understand that: Material type and density. Flange dimensions and tolerances. Necessary Angle and Angle tolerances. Angle inside the arc. Blank size. In the absence of any of these data, supervisors will need to make educated assumptions. The part is now at risk of being inaccurate. An important initial step is to obtain detailed drawings.   Tool selection The sketch is used to select the tool. There are several options for you to choose from: air bending, bottom bending, coinage or custom use. For example, if the layout requires a bottom tool and the internal arc length is equal to the metal density. For that particular type of machine, you should use a tool with at least the same precision as the tool manufacturer recommends. No matter how accurately the bending machine is installed, worn equipment will not produce the right product.   Calculated tonnage It should be easy for the operator to estimate the tonnage required. Regarding air bending, there seem to be tonnage charts available. A reasonable calculation for bottom bending is nearly three times the air bending tonnage. Stamping requires about eight times the bending tonnage of air. The supplier will provide tonnage estimates for custom application tools. Do not attempt to bend until you have determined the tonnage required and compared it to the tonnage provided.   Select a bending machine If you have only one press in your workshop, you can skip this step. If you have more than one press, make sure that the press you choose is best for the task at hand. The center of the press has a tonnage per inch limit. Multiply the length of the side panels by 0.6 to find the tonnage per inch of the press, then start dividing your estimate by the tonnage of the machine. For items 12 inches wide, the maximum tonnage of the machine center should not be higher than 25 tons. 25 tons over 12 inches will produce compression overload. This is a bad decision because it could permanently damage the ram. When using tonnage control (manual and CNC), be sure to use only the amount required for the torsion parts and do not exceed the tonnage threshold in the middle. Also, keep in mind that overload of the bender is only allowed when the bottom is compacted, cast, or air bent with dedicated tools. Select tool location If the required tonnage exceeds the concentrated weight limit at the center of the system, you may be able to complete the task off-center. However, you should first verify that the bender supplier allows eccentric loading to proceed. Eccentric work is acceptable as long as you follow the manufacturer's guidelines. If you have more ideas, please contact us! Tel: +86 -18855551088 Email: Info@Accurl.com Whatsapp/Mobile: +86 -18855551088

First, the basic concept and classification of bending machine Step 1 Define A bending machine is a device that produces plastic deformation in a mold by applying pressure to a sheet metal to form a predetermined Angle or shape.   2. Main types Mechanical bending machine: pressure is provided by mechanical transmission (such as gears, crankshaft), simple structure but low precision, suitable for small machining. - Hydraulic bending machine: driven by hydraulic system, high pressure, high stability, suitable for medium and thick plate processing. Numerical control bending machine (CNC) : through the CNC system to control the bending Angle, pressure and rear stop material positioning, high precision, high efficiency, suitable for mass production of complex workpieces. - Servo electro-hydraulic bending machine: Combining hydraulic and servo motor technology, energy saving and fast response speed. Second, the core structure and function of the bending machine 1. Fuselage: The frame that supports the overall structure must have high rigidity to withstand bending forces. 2. Slide block: a pressure component that moves up and down to connect the upper die and apply pressure. 3. Workbench: a platform for fixing the lower die, usually equipped with an adjustable V-shaped slot. 4. Hydraulic system (hydraulic/electro-hydraulic model) : composed of oil pump, cylinder, valve group, etc., to control pressure and stroke. 5. Back Gauge: the key component of CNC bending machine, which is used for plate positioning and directly affects bending accuracy. 6. Numerical control system (CNC model) : input parameters (Angle, pressure, stroke) to control the bending process. Third, basic knowledge of bending process 1. Bending principle - Pressure is applied to the sheet through the die to cause plastic deformation of the material. - Key parameters: bending Angle, bending radius, bending force (related to material thickness and strength).   2. Material characteristics - Elastic modulus: the ability of the material to resist deformation (such as stainless steel, which needs over-bending compensation). - Minimum bending radius: Avoid material cracking, depending on material thickness and type. - Springback: The Angle bounce of the material after unloading needs to be compensated by bending or mold design.   3. Bending force calculation - Formula: 'P = (1.42 × σb × L × t²)/V' -σb: Material tensile strength (MPa) -L: Bending length (mm) -t: Material thickness (mm) -V: lower die opening width (mm)   Four, mold selection and use 1. Mold type - Upper die (Punch) : Common shapes include sharp knife die, curved knife die, gooseneck die. - Lower Die (DIE) : The bending radius is determined by the width of the V-shaped groove, which should be selected according to the thickness of the material (usually the width of the V-port = the thickness of the material ×8). - Special mold: used for rolling, flattening, multi-step molding and other processes.   2. Mold materials - Tool steel (Cr12MoV), alloy steel, heat treatment to improve wear resistance.   3. Matching principle - Ratio of plate thickness to V-groove width (usually 1:8) to avoid material deformation or mold damage.   5. Operation process and safety specifications 1. Procedure - Equipment inspection (hydraulic oil, lubrication system) → Select mold → input parameters (Angle, pressure) → Position plate → bending test → adjustment compensation → mass production.   2. Safety precautions - Wear protective gloves/glasses to avoid cutting the board burrs. - Do not put hands in the mold area. - Check the tightness of the hydraulic system regularly to prevent oil leakage.   Six, common problems and solutions 1. The rebound is too large - Solution: Increase bending Angle compensation, use mold with correction function or CNC system. 2. Bending crack - Reason: poor material ductility or bending radius is too small → Replace soft material or increase R Angle. 3. Size deviation - Calibrate rear stop, check mold wear or NC system parameters.   Seven, equipment selection and market positioning suggestions 1. Target customer analysis - Sheet metal processing plants, chassis cabinet manufacturers, auto parts companies, etc. 2. Equipment selection - Small enterprises: hydraulic CNC bending machine is recommended (economical and practical). - High-end market: servo electro-hydraulic bending machines or high-precision models with laser detection. 3. Technology trends - Intelligent: Integrated AI Angle compensation, automatic mold change system. - Energy saving: servo motor drive to reduce energy consumption. Maintenance and maintenance 1. Routine maintenance - Clean mold and table debris. - Check hydraulic oil level and oil quality. 2. Regular maintenance - Replace hydraulic oil filter every 500 hours. - Lubricate moving parts such as guide rails and lead screws.

Choosing between an NC Press Brake and a CNC Press Brake depends on several factors, including production needs, budget, part complexity, and desired level of automation. Here are some considerations to help guide your decision: Production Volume: Low to medium-volume production with simpler parts: An NC Press Brake might suffice. High-volume or complex production requiring multiple intricate bends: A CNC Press Brake will provide the necessary precision and automation. Part Complexity: If the parts are simple and do not require frequent changes or complex bending sequences, an NC press brake might be more cost-effective. If the parts involve complex geometries, multi-step operations, or tight tolerances, a CNC press brake will be more suitable. Budget: For businesses on a tight budget or with simpler bending needs, an NC press brake may be the better choice. For companies looking to maximize automation and reduce human error, the initial higher cost of a CNC press brake can be justified by the improvements in efficiency, quality control, and throughput. Workforce Skill Level: An NC press brake might require more skilled operators who are proficient in manual setup and adjustments. A CNC press brake is easier to operate with less technical expertise, as the machine itself compensates for many manual interventions. Summary: NC Press Brake: Suitable for simpler, low-to-medium volume production with straightforward bending requirements. Offers moderate precision and requires more manual setup. CNC Press Brake: Best for high-precision, complex tasks with high-volume production needs. It offers superior automation, flexibility, and efficiency but comes with a higher initial investment. Ultimately, the choice between NC and CNC depends on your specific manufacturing needs and how much complexity, automation, and precision are required for the jobs at hand. If you have more ideas, please contact us！ Tel : +86 -18855551088 Email : Info@Accurl.com Whatsapp/Mobile : +86 -18855551088

accurl press brake is the key component for controlling the movement of the bending machine. By precisely controlling the speed, position and torque of the motor, the servo system enables the table and upper die of the bending machine to carry out accurate movement according to the program, so as to complete various bending operations. A servo system usually consists of the following components: 1. Servo motor: electric drive device, through the motor rotation to drive the main movement of the bending machine, such as the up and down movement of the upper and lower die, or the precise control of the bending Angle. 2. Servo driver: Control the speed and steering of the servo motor to ensure the precise operation of the motor according to the predetermined procedure. The drive receives instructions from the CNC control system and translates them into actions that the motor can perform. 3.CNC control system: It is usually realized by the computer numerical control (CNC) system, which calculates and outputs the control instructions according to the data input by the program, so as to control the action of the servo drive and the motor. 4. Feedback system: The position, speed and torque of the motor are monitored in real time through sensors (such as encoders), and the data is fed back to the control system to ensure that the system is accurately adjusted and any errors are corrected. The advantages of servo system are high precision, high efficiency and high flexibility. It enables the bending machine to perform a variety of complex bending operations, and can precisely control the bending Angle, bending depth and speed, improving production efficiency and processing quality.   In short, the servo system enables CNC bending machines to perform automated bending operations efficiently and precisely through sophisticated motor control and feedback mechanisms. If you have more ideas, please contact us！ Tel : +86 -18855551088 Email : Info@Accurl.com Whatsapp/Mobile : +86 -18855551088
